750 GAL CHERRY BURRELL REACTOR, S/S, 60/100#
One (1) used 750 gallon Cherry Burrell reactor, stainless steel construction, 60" diameter x 66" straight side, dished top and bottom, rated 60 psi and full vacuum at 350 F internal, jacketed for 100 psi at 350 F, top entering off center Lightnin agitator drive with mechanical seal model XLDS-200F driven by 2 HP, 575 volt motor, with two tier 3 blade turbine agitator, 20" manway, 1.5" top nozzle, 3" center bottom outlet, on 3 stainless steel legs with 3' discharge height, serial# E-086-91, national board# 3691, new 1991.
