Hewlett packard hp 4194A phase analyzer
CHECK OUT MY SITE FOR ADDITIONAL MIXERS, COMPUTER
ACCESSORIES,SPEAKERS, PRO VIDEO AUDIO GEAR EQUIPMENT, ETC...
SCROLL TO THE BOTTOM OF THE PAGE
HEWLETT PACKARD PHASE ANALYZER 4194A
* High Accuracy and Wide Range:
100Hz to 40MHz, 0.1m to 1.6M , 0.17%
10 kHz to 100 MHz, 0.1 to 1M , 1.5% when used with the HP / Agilent 41941A/B
10 Hz to 100MHz, -107dBm to +15dBm, 0.1dB resolution
* Flexible Measurement, Computation and Analysis Capabilities on a Color Graphic Display
HP / Agilent 4194A Specifications:
Measurement Parameters: |Z|, |Y|, , R, X, G, B, L, C, D, Q. 20 parameter combinations are available.
Test Frequency: 100 Hz - 40 MHz (cable length: 0m), 100Hz - 15 MHz (cable length: 1m), 1mHz resolution
OSC Level: 10 mV - 1Vrms ( 10MHz), 10mV - 0.5Vrms (> 10MHz), 3 digit resolution
DC Bias:0 - +40V, 10mV resolution
Measurement terminal: 4 - terminal pair configuration
Measurement Range and Max. Resolution:
ITEM IS IN GREAT WORKING USED WORKING CONDITION. COSMETICALLY ITEM LOOKS GREAT. RECENTLY REMOVED FROM A PROFESSIONAL WORKING ENVIRONMENT, IN WORKING ORDER.
SEE ALL NECESSARY DETAILS BEFORE PLACING
