Honeywell M7282A modutrol-iv motor actuator hvac damper
HONEYWELL M7282A MODUTROL-IV MOTOR ACTUATOR HVAC DAMPER
Honeywell M7282A-1022 Modutrol-IV Motor, Valve Motor, Dampers Control Motor/Actuator
M7181, M7184 150 lb-in. (17 N m.).
M7182, M7185 60 lb-in. (6.8 N m).
M7294 300 lb-in. (34 N m).
Motor Torque lb-in. in. mm
Dead Weight Load On Shaft:
Power or Auxiliary End: 200 lb (90.8 kg) maximum.
Maximum Combined Load: 300 lb (136 kg).
Ambient Temperature Ratings:
Maximum: 150 F (66 C) at 25% duty cycle.
Shaft: 3/8 in. (9.5 mm) Square.
M7284, M7285, M7294 have dual-ended shaft.
M7281, M7282 have single-ended shaft.
Auxiliary Switch Ratings (Amperes):
One Contact Ratinga Amps 120V 240V
a40 VA pilot duty, 120/240 Vac on opposite contact.
