50A digital dc pwm motor speed controller - assembled
50A Digital DC PWM Motor Speed Controller - Assembled
50A Digital DC PWM Motor Speed Controller (Not a Kit)
This is an assembled unit of a kit we nomally sell. Unfortunately, the kit is sold out and we only have these assembled units in stock. Here is a chance to get a product that normally sells for $59.99 for only $54.99. This deal will end once we get the kits in stock again!
THE DISPLAY IS INCLUDED WITH THIS PRODUCT. THE COST BREAKDOWN IS $54.95 FOR THE CONTROLLER AND $14.95 FOR THE DISPLAY FOR A TOTAL OF $69.90.
Supply / Load Voltage: 9 to 30V DC (12V DC Recommended)
Optional LCD Module (Included)
50 Amps Maximum Continuous Current (@ 100Hz)
Frequency: Fixed (100Hz) or Adjustable (244 Hz to 3.125 KHz)
PWM Duty Cycle Range: 0% - 100%
High efficient design using High-Power 202A MOSFET for cool operation
Includes large double Spade Terminals for ease of connection
Applications: Motor Control, HHO, DC / LED Light Dimmer, Heating Control, etc...
Control the speed of a DC motor without sacrificing torque. This Pulse-Width-Modulation (PWM) DC motor controller can provide up to a maximum continuous current of 50A to your DC motor or other DC load thanks to a digital microcontroller based (PIC) design and highly efficient High-Power 202A MOSFET for cooler operation.
An optional LCD module is included that will precisely indicate the currently set frequency and duty cycle for accurate control of the PWM signal.
The controller has two modes of operation: Fixed or Variable frequency. The fixed frequency mode of operation runs the controller at 100 Hz. In the variable frequency mode of operation, the frequency is adjustable from 244 Hz to 3.125 KHz. Duty cycle is fully adjustable from 0% to 100% in both modes.
A DC fan is included with the motor controller for robust reliable continued operation under heavy loads. Please note that DC fan is only designed to work with a supply voltage of up to 12V DC. For higher voltage operation, the DC fan will need to be replaced.
The item you are purchasing is a kit. As such, returns are only authorized on kits that haven't been opened or assembled. If you find the kit to be missing parts, then by all means contact us and we will get the right parts to you ASAP. If you assembled the kit incorrectly and it doesn't work, then email support is available to you and we can even get you in touch with the manufacturer (if we didn't make the kit) so you can get help on a first hand basis.
