Tektronix WFM1125 High Definition Waveform Monitor
The WFM1125 is in a series of Tektronix high definition waveform monitors to both acquire and display the SMPTE292M television signal in its native digital format. All signal processing is mathematical, resulting in very high display accuracy, even in magnified modes. The only analog processing is an instrument reference to external tri-level or NTSC sync and conversion of the digital signal for output to an external analog picture monitor.
* Waveform/Vector Monitor for HDTV Baseband Video
* Two SMPTE 292M, 1.485 Gb/s Serial Component Inputs
* Multi-format Option Adds 1920x1080i/50, 1920x1080/24sF and 1920x1080p/24 Formats
* Parade and Overlay Waveform Displays in RGB, GBR or Y/Pb/Pr
* Vector display for 240M or 274M Colorimetry
* Tektronix Diamond, Lightning and Bowtie Displays
* Expanded Waveform Scales for Extended Accuracy
* Waveform Save Mode for Signal Comparison
* NTSC or Tri-level External Reference
* Analog Y/Pb/Pr and Digital Picture Monitor Outputs
* AES/EBU Output of Audio Embedded in SMPTE 274M Data (1920x1080i/60 Format)
* Gamut, Status and Line-by-line CRC Monitoring
* VGA Display and Screen Output
