16" swg 120" cc birmingham dlc-16120 special deal engin
16" Swg 120" cc Birmingham DLC-16120 Special Deal ENGIN
16" Swing 120" Centers Birmingham DLC-16120 Special Deal ENGINE LATHE, 10 HP, 16 Speed, 4-1/8" Spind
Model: DLC-16120 w/Removable Gap Block
Note: the photo shows the 60" centers model
Special deal includes Free Delivery to all the lower 48
States and a Free Taper Attachment (installed)
10 HP motor delivers power thru all spindle speeds
Spindle gears, shafts and bearings are lubricated by pumped bath of oil
Induction hardened and ground bedways
D1-8 Camlock spindle with 4-1/8" spindle bore
16 Spindle speeds, 26 - 1,700 RPM
Rapid power traverse to carriage and cross slide
Multiple disc clutch for efficient spindle starting and reversing
Spindle nose type (Camlock): D1-8
Spindle speed range: 26 - 1,700 RPM
Spindle center to bedway: 8-5/8"
Threads per inch (No.) range (TPI): (42) 7/16 - 80
Metric threads (No.) range (mm): (37) 0.5 - 80
Module threads (No.) range (mm): (32) 0.25 - 40
Diametral threads (No.) range (DP): (42) 7/8 - 160
Long. feeds (No.) range (in/rev): (45) 0.0017 - 0.058
Cross feeds (No.) range (in/rev): (45) 0.0009 - 0.029
Leadscrew diameter (in): 1-9/16"
Main drive: 10 hp, 220/440V 3 ph
Maximum workpiece weight: 1,100 lbs.
Overall Dimensions: 182" L x 47" W x 54" H
12" 3 Jaw Chuck with reversible jaws
Steady rest capacity 1-1/8 - 6-1/4"
Follow rest capacity 3/4" - 3-1/8"
Coolant System w/Full Length Splash Guard
12" Cap. Larger steady rest with roller jaws
5C Hand lever type collet closer "JFK" USA
