TLC5941NT LED Driver DIP; TLC5940 TLC5940NT TLC5941 PWM
This is almost a drop-in replacement for the very popular TLC5940NT and has a near-identical pinout.
The key differences are a maximum current rating of 80mA (vs. 120mA) and a lack of an EEPROM.
The TLC5941 is a 16-channel, constant-current sink, LED driver. Each channel has an individually adjustable 4096-step grayscale PWM brightness control and a 64-step constant-current sink (dot correction). The dot correction adjusts the brightness variations between LED channels and other LED drivers. Both grayscale control and dot correction are accessible via a serial interface. A single external resistor sets the maximum current value of all 16 channels.
The TLC5941 features two error information circuits. The LED open detection (LOD) indicates a broken or disconnected LED at an output terminal. The thermal error flag (TEF) indicates an overtemperature condition.
* 12-Bit (4096 Steps) Grayscale PWM Control
* Drive Capability (Constant-Current Sink)
* LED Power Supply Voltage up to 17 V
* Controlled In-Rush Current
* LOD: LED Open Detection
* TEF: Thermal Error Flag
* Monocolor, Multicolor, Full-Color LED Displays
