Ati walk behind electric/hydraulic boom lift crane 1K
ATI Walk Behind Electric/Hydraulic Boom Lift Crane 1K
Hand-held controller functions tested:
* Boom retracted/extended: 54"-96"
* Boom rotated clockwise and counter clockwise: 90 degrees in either direction
* MANUFACTURER: ATI (AIR TECHNICAL INDUSTRIES)
* CAPACITY BOOM RETRACTED: 1000 LBS.
* CAPACITY BOOM EXTENDED: 500 LBS.
* MAX. LIFT HEIGHT WITH BOOM RETRACTED: 102"
* MAX. LIFT HEIGHT WITH BOOM EXTENDED: 144"
* FLOOR TO HOOK HEIGHT WITH BOOM RETRACTED, LOWERED: 36"
* FLOOR TO HOOK HEIGHT WITH BOOM EXTENDED, LOWERED: 18"
* MAX. REACH BEYOND WHEELS: 82"
* BOOM LENGTH, FULLY ADJ. FROM: 54"-96"
* DIMENSIONS OF LIFT (not including boom): 84"L x 32"W x 33"H
* OVERALL DIMENSIONS: 124"L x 32"W x 73"H
* 2 - TUFLEX LIFTALL POLYESTER SLINGS, TYPE: EN60 X 6 FT, VERTICAL: 5300LBS., CHOCKER: 4200LBS., BASKET: 10600LBS.
* 2 - EXTENSION/SUPPORT BARS
