Hp agilent 8901B modulation analyzer fm/am/distortion
hp Agilent 8901B Modulation Analyzer FM/AM/Distortion
This hp 8901B modulation analyzer is used, checked, and is in good condition.
One photo shows FM deviation; another shows THD+N.
* 030 - High selectivity. Option 030 includes rear-panel external local oscillator connections. Two filter options (032 through 037) must be selected with Option 030.
* 032 - 12.5 kHz adjacent channel filter
* 033 - 25 kHz adjacent channel filter
The Agilent Technologies 8901B Modulation Analyzer combines four precise measurement functions into one fully automatic, GPIB programmable instrument. It includes a power meter, modulation analyzer, frequency counter, and audio analyzer. For precise signal analysis, the 8901B Modulation Analyzer provides the performance you need, the features you want, and the reliability and serviceability you expect.
RF Power delivers the accuracy and resolution of a high performance power meter. The 8901B with the Agilent Technologies 11722A Sensor Module measures power from +30 dBm to 20 dBm at frequencies from 100 kHz to 2.6 GHz. The 8901B accepts all Agilent Technologies 8480 series power sensors for extended measurement capability.
AM and FM measurements offer 1% accuracy (3% accuracy for M) and fast one-key operation. The 8901B has extremely low internal noise, and very low AM/ M and M/AM conversion, for accurately measuring residual and incidental AM, FM and M on a wide range of simple and complex modulated signals.
RF Frequency of complex modulated signals can be difficult to measure, but not with the 8901B. Automatically tuning to the largest input signal or to any user specified frequency, the 8901B counts with 10 Hz resolution.
Audio distortion, frequency, and level measurements provide comprehensive characterization of the modulation signal.
You will receive the same 8901B shown in the photos. No other equipment is included in this sale. The ST1000A stereo generator is not included.
