Lagun cnc vertical machining center vmc-3516-s
LAGUN CNC VERTICAL MACHINING CENTER VMC-3516-S
Made by Republic - Lagun CNC Corporation of Harbor City, California.
This is a Lagunmatic VMC3516 3 Axis Vertical Machining Center in working condition.
This machine retails for up to $75,000.00!!
* Lagunmatic 1000-32 CNC Control
Machining Capacity: X Axis Travel............................24" Y Axis Travel............................16" Z Axis Travel............................20" Max. Load...............................2,700 lbs. Table: Table Size...............................15 5/8" x 35.5"T-slots (3)................................11/16" Table Center to Column..........7.75" x 23.66"Table Top to Floor....................29.5" Spindle Head: Motor.......................10 HP Spindle Speed...........60 to 8,000 rpmMax-Torque at Spindle.....53 ft.-lbs.@ 1,500 RPM Taper .......................40 TaperSpindle to Table:
Minimum......................5 3/4"
Maximum.....................30 3/4"Spindle Center to Ways........15 5/8" Spindle Center to Column.........21 7/8" Automatic Tool Changer: Tool Storage Capacity ..................18 toolsTool Selection.......................Random/Bi-DirectionalMax. Adjacent Tool Dia......... 2 3/4" Max. Dia. w/o Adjacent Tool.......5 1/2" Max. Tool Weight........................15 lbs. Max. Tool Length .....................12" Performance: Positioning Accuracy.......... 0.00015"Repeatability....................... 0.0001"Resolution.......................0.0001" Rapid Traverse (X & Y)............1,200 ipm Cutting Feed Rate...............0 to 250 ipmFeed Rate Override.............0 to 150% Axis Thrust (X-Y-Z) .............7,022 lbs. General: Air Pressure Requirements.....100 PSI Coolant Capacity ......................38 gallons Coolant Flow ......................10 GPMVoltage: 230 Volts, 3 Phase Working Area Required: 120" x 120"Overall Dimensions: 122" x 127" x 119" high
Specifications are subject to verification
Republic-Lagun CNC Corporation builds a highly regarded line of CNC-controlled vertical machining centers, knee machining centers and universal turning centers. Republic-Lagun CNC machines are unmatched in quality, performace and reliability.
