LM358 dual op amp ic kit with pcb (#1410)
LM358 Dual Op Amp IC Kit with PCB (#1410)
This is the popular LM358 Dual Op Amp DIP IC Design Kit #1 with PCB. It has 4 pieces of the very popular LM358, Dual Op Amp in the DIP-8 package (with leads). This IC has 2 independent Op Amps; just use the ones you need. The data sheets for this IC, along with hundreds of others, are located at .
This kit also includes different values of 1/4 Watt Resistors, Aluminum & Ceramic & Tantalum Capacitors, NPN & PNP Transistors, Signal & Power & Zener Diodes, Electret Microphones, Bridge Rectifiers, Trimpots, LEDs, Crystals, Pushbutton Switches, a miniature Speaker, and some Electronic Hardware for your I/O connections.
To further help with your circuit development, you also get a 162 plated-thru hole PCB and some IC sockets. This PCB has 4 mounting holes, is 1.1" x 2.0", and is double-sided.
With these parts, you can make numerous circuits, such as active filters, pre-amps, signal conditioners, function generators and much more. There are no SMT components in this kit. Search the web for incredible circuits to build. The Datasheets and Application Notes for the ICs and Transistors, along with hundreds of others, are located at DATASHEETS. We supply the parts, you supply the ingenuity. You get the following:
LM358, Dual Op Amp, Single-Supply, DIP-8
NightFire, 162 Holes, Double-sided, FR-4
