Nsk nakanishi high speed air jig grinder planet 2000
Nsk Nakanishi High Speed Air Jig Grinder Planet 2000
HIGH SPEED AIR JIG GRINDER PLANET 2000 180,000~200,000 min-1(rpm)
Energy saving mechanism usable with a compact air compressor of 0.4 kw (1/2HP)
As tip tools, mounted wheel of 1.6 mm, diamond, CBN and special tools can be used..
PLANET 2000 : 180,000~ 200,000 min-1(rpm).
Planet 2000 Jig Grinder Collet 1.6 mm (CH20-1.6) : 1 pc. Grindstone Arbor for Special Purpose ( 1.0 mm, 1.4 mm) : 1 pc. each Grindstone with Arbor ( 1.6 mm) : 3 pcs. Intake Air Hose (K-259) : 6 mm x 6 ft Anti-swivel Bar Wrench (K-220) : 1 pc. Filter Joint (FJ-01)
Speed 180,000~200,000 min-1(rpm)
Proper Air Pressure 29~42PSI
Air Consumption 1.59CFM (42PSI)
Processable Diameter 0.02"~ 0.20"
Max. Grindstone Diameter 0.08"
