Kelvinator lab/pharmacy refrigerator w/partlow rft
Kelvinator Lab/Pharmacy Refrigerator w/PARTLOW RFT
Kelvinator Refrigerator VGM-26-3
Temperature Range: 2.5 C/36.5 F to 5.5 C/41.9 F
Dimension EXT: 83 H x 33 W x 32.5 D
Dimension INT: 59 H x 28 H x 28 D
Interior Lighting: Fluorescent
Records temperature on a 10" chart. Twelve ambient compensated ranges within -30 F to 1100 F, permit application diversity from refrigeration to high temperature ovens. Standard clock rotations 12, 24 and 48 hour, 7 day, others available. Choice of electric or spring wound chart drives available. Wall mounted (brackets furnished) or flush mounted. UL listed.
Chart Marking: Felt Tip Cartridge/optional pressure sensitive charts
Chart Drive: Electric with toggle switch, or spring wound.
Chart Rotation Periods: 24 and 48 hour, 7 day, other options
Flush Mount Cutout: 13-1/2" W x 12-11/16" H
A one pen, 10" circular chart, temperature recorder.
Available with 12, 24, or 48 hour, or 7 day rotation times for 125VAC, 60 Hz operation, and others.
Seventeen operating ranges covering -30 F to 1100 F
