Digital photo laser tachometer rpm lcd non contact tool
Digital Photo Laser Tachometer RPM LCD Non Contact Tool
* Digital display gives exact RPM with no guessing or errors.
* The last value/max.value/min. value will be automatically stored in memory and can be displayed by turn anytime
* Display: 5 digits, 18mm LCD, with function annunciation
* Text Range: 2.5 to 99999 RPM
* Resolution: 0.1 RPM (2.5 to 999.9RPM), 1 RPM (over 1000 RPM)
* Accuracy: +/- (0.05% + 1 digit)
* Sampling Time: 0.8sec. (over 60 RPM)
* Memory: Last value, Max. Value, Min. Value
* Detecting Distance: 50 to 200 mm / 2 to 10 inch (LED) , 50 to 500 mm / 2 to 20 inch (Laser)
* Circuit: exclusive one-chip of microcomputer LSI circuit
* Battery: 6F22 9V x 1(included)
* Power consumption: Approx. 35 mA (LED), Approx. 30mZ (Laser)
* Sixe: 131 x 70 x 29 mm(approx)
* Reflective Tape (24 inches) x 1
