Baum nd-10 multi spindle hydraulic drill - 7 heads
* Hydraulic Multi-Spindle Paper Drill
* 7 Drilling Heads Installed
* Condition: Excellent condition throughout. This drill is a workhorse! Built tough, and VERY heavy duty. It will make the new owner very happy.
* Many Extra Drill Bits - Mostly New
* The ND-10 is flexible. It quickly drills any job up to 10 holes in one stroke, so big drilling jobs can be completed quickly and economically. It's easy to adjust for a variety of multiple hole patterns simply add and adjust drilling heads by sliding them along the splined shaft. A special three-drill head is available with drill bits on 1" centers.
* A touch to the foot pedal brings the drilling heads down to the table under hydraulic power. The paper is drilled and the heads are released automatically and returned to the starting position. The speed of the heads on the downward stroke is adjustable, providing you with the most-efficient drilling and production operations on all types of jobs and paper stocks.
* The ND-10 features all cast iron construction, and is quality built by highly trained technicians with years of experience. The ND-10 is designed and built to stand up to years of heavy-duty drilling use. It is a drill you can depend on to get your jobs done productively and on time.
* High Production Multi-Hole Drilling
* Drills Up To 10 Holes in One Stroke
* Maximum Drill Bit Diameter 1/2"
* Variable Speed Stroke Control
* Flexible Side Guide Adjustments
* Maximum Number of Drill Heads: 10 Heads
* Drill Sizes Available** (2" capacity): 1/8" to 1/2" / 3 to 13 mm
* Drill Sizes Available (2-1/2" capacity): 1/4" to 1/2" / 6 to 13 mm
* Center to Center Distance Maximum: 21" / 53 cm
* Center to Center Distance Minimum: 1-1/4" / 3.2 cm
* Minimum Distance Between Holes w/ Adj. Stops: 3/8" / 9.5 cm
* Minimum Distance Between Holes w/ Fixed Gauges: 1/4" / 6 mm
* Maximum Drilling Capacity: 2-1/2" / 6.35 cm
* Strokes per Minute (adjustable): 18 to 26
* Backgauge Adjustment: 0 to 9" / 0 to 23 cm
* Vertical Adjustment of Individual Heads: 1/4" / 6 mm
* Table Height: 38" / 96.5 cm
* Overall Height: 60" / 152 cm
* Floor Space Needed: 35" x 40" / 89 x 102 cm
* Net Weight (approximate): 1350 lbs / 675 kg
