Agilent hp 141T 8552B 8553B spectrum analyzer system
Agilent HP 141T 8552B 8553B Spectrum Analyzer System
Powers up, appears fully operational. CRT look bright and crisp, storage mode looked good.
Complete system, 141T storage mainframe, 8552B IF section, 8553B RF section (refurbished).
Rear panel of 141T has one broken rear leg and a non-standard CRT yoke cover.
7 Day unconditional right of return.
The 141T Spectrum Analyzer System features absolute calibration of frequency and amplitude, high resolution and sensitivity, wide dynamic range, and simple to interpret display output. Four plug-in tuning sections (all sold separately) utilize a wide range of plug-ins and permits measurements at frequencies ranging from 20Hz to 18GHz (to 40GHz with external mixer). Features an easy to read 8 x 10 cm variable persistence CRT with a writing rate from 0.2 s to 15 s. Maximum storage time is over 2 hours at reduced brightness. The modularity of this system allows you to keep pace with changing measurement requirements.
The 8553B RF Section is for use in a 141T Spectrum Analyzer System (sold separately). The unit covers the frequency range of 1kHz to 110MHz. This frequency range includes audio, video, navigation aids, communications basebands, broadcast AM and FM, and TV. This analyzer features high sensitivity, stability and resolution. 10Hz frequency accuracy with the 8443A Tracking Generator (sold separately); Calibrated amplitude from -142 dBm to +10 dBm, (18 nV to 0.7 V) ; Accuracy: 1.25 dB.
