100 foot alphawire 3050 black electrical hook-up wire
100 Foot AlphaWire 3050 Black Electrical Hook-Up Wire
AlphaWire P/N 3050-BLACKThis is made for the internal wiring of appliances or electronic equipment that are not subject to movement or mechanical damage. The wire is a single strand copper wire 3050-BLACK is 1 x 1 Hook-Up wiringConductor: 24 (7/32) AWG TC Insulation: 0.016" Wall, Nom. PVCLength: 100 feetDiameter of wire with insulation: 1.45mm (0.055 inches) 3050 AlphaWire Datasheet
Physical & Mechanical Properties
* Temperature Range: -40 to 105°C
* Bend Radius: 10X Cable Diameter
* Pull Tension: 3.5 Lbs, Maximum
Electrical Properties (For Engineering purposes only)
* Inductance: 0.07 H/ft, Nominal
* Conductor: DCR 25 /1000ft @20°C, Nominal
