1996 matsuura #ra-1F cnc vertical machining center
1996!! MATSUURA #RA-1F CNC VERTICAL MACHINING CENTER
* 20-Position Automatic Tool Changer.
Number of Usable Pallets on Machine: 2
Overall Pallet Surface Area: 23.6" x 14.9"
Maximum Load Weight: 550 lbs.
Pallet Change Time: 9 secondsTravels:
Spindle Speeds Range: 30 - 8,000 rpm
Pallet Center to Spindle Gauge Plane: 5.9" - 24"
Motor: 5.5 kW (30 min.) / 3.7 kW (continuous)Movement Rates:
Rapid Traverse (X & Y): 944.8 ipm
Rapid Traverse (Z): 590.5 ipm
Feed Rates (X, Y, Z): 0.04 - 393.7 ipmAutomatic Tool Changer:
Number of Tool Positions: 20
Maximum Tool Length: 11.8"
Maximum Tool Weight: 13.2 lbs.
Maximum Tool Diameter: 3.15"
Tool to Tool Change Time: 1.8 secondsGeneral:
Overall Dimensions of Machining Center: 110" x 110" x 120" tallComes as shown in pictures.
