Tektronix 067-0625-00 peak to peak calib
Tektronix 067-0625-00 Peak To Peak Calib
Unit appears fully operational. 0V out with 1.1 V PP applied ( as read on the SG503 amplitude dial).. Frequency response looked good against an SG503 up to 250MHz
The Tektronix 067-0625-00 Peak-to-Peak Detector is designed to measure the output voltage flatness of 50 Ohm, constant-amplitude signal generators. The detector has a frequency range of 50 Hz to 500 MHz and requires a 1.2V p-p input.
