Bear-aide railroad template
This unique 8 inch by 11 inch template is used to draw 1"=20' diagrams of railroad accident scenes with either a medium ball point pen or a pencil. The one inch equals twenty feet scale is compatible with other Bear-Aide traffic templates. Registration marks are provided on major railroad equipment cutouts to facilitate drawing of various sized cars and engines. In addition, a scale ruler, a protractor, and a compass are provided. The template includes cutouts for signals and railroad ties. This notebook-sized template has holes to fit a three ring binder.
