62.5" tbl 7.5HP spdl kearney&trecker 307-S12 horizontal
62.5" Tbl 7.5HP Spdl Kearney&Trecker 307-S12 HORIZONTAL
62.5" Table 7.5HP Spindle Kearney&Trecker 307-S12 HORIZONTAL MILL, Universal Head Power Overarm
MODEL: 307-S-12, S/N: 53-1003-19, NEW: 1970
TABLE SIZE .............................. 62-1/2" X 12"
VERTICAL KNEE TRAVEL .................... 16"
FEED RANGE LONGITUDINAL & CROSS(16) ..... 1/4 - 32 IPM
FEED RANGE VERTICAL(16) ................. 1/8 - 16 IPM
HORIZONTAL SPINDLE SPEEDS (24) .......... 25 - 2000 RPM
VERTICAL SPINDLE SPEED RANGE(8) ......... 100 - 1600 RPM
SPINDLE DRIVE ........................... 7-1/2 HP
FEED DRIVE .............................. 1-1/2 HP
COOLANT PUMP DRIVE ...................... 1/4"
APPROXIMATE SIZE ........................ 80"D X 84"W X 83"H
- POWER VERTICAL OVERARM WITH DOUBLE SWIVEL HEAD
& HAND QUILL ADJUSTMENT & MICROMETER STOP
- 7-1/2 HORSEPOWER SPNDLE DRIVE MOTOR
