> Igbt everlast 200AMP mig stick welder 220V 200A 200AMP
Igbt everlast 200AMP mig stick welder 220V 200A 200AMP
MIG 200amp Mig/Arc Welder with IGBT Module technology (Spool Gun optional)
220-240VAC (1) Single Phase 50/60hz
Rated Input Current: 22 Amps
Voltage Adjusting Range: 14 3v~23 3v
Current Output Range: 10-~200amps (MIG/MAG) and 10-140amp Arc (Stick Welder)
Suitable Wire: .6, .8 solid/flux cored wire. (will take a ten pound spool) and optional spool gun will take 3lb spool.
Duty Cycle: 200amp duty cycle is 60%
TOUGH: 100% duty cycle at 85A, 60% duty cycle at 110A, 35% duty cycle at full power
EXCELLENT REACH - 9' power cord, 9' ground clamp, 9' mig torch
1 - Heavy-Duty MIG/MAG torch
2 - Tips for torch (.6 & .8) (1 already installed in torch)
2 - Wire feeding guides (including 1 mounted in machine)
1 - 7-pin female connector to fit 7-pin male on machine for optional spool gun
1 - heavy-duty ground clamp
