Hp 5315B universal frequency counter w/ option 001
HP 5315B universal frequency counter with option 001. In good condition, showing normal wear and tear in the form of small scuffs and scratches. Tested and guaranteed not DOA. No other hardware or cables included, only the counter as shown above.
HP 5315B Frequency Counter Description:
The 5315B Frequency Counter has a 100MHz frequency range and also has ratio and totalize measurement capabilities. Period range from 10 ns to 105 s, Time interval range from 100 ns to 105 s. Time interval average range to 105 s. Display is 8-digit LED for increased resolution.
HP 5315B Frequency Counter Specfications:
* Frequency range: 0.1Hz to 100MHz.
* Sensitivity: 10mV rms to 10MHz, 25mV rms to 100MHz, 75mV p-p pulse at 5ns.
* Functions: frequency, period, time interval, ratio, and totalize.
