> Wade model 73 metal lathe instruction & parts manual
Wade model 73 metal lathe instruction & parts manual
This is a reproduction, not a photocopy, of an original Wade Model 73 Metal Lathe Operator's and Parts Manual. See index below.
Specifications................................1
Table of Contents.............................2
Variable Speed Drive..........................3
Variable Speed Drive Parts List...............4
Variable Speed Drive Assembly.................5
Gear Box Assembly.............................6
Compound Slide Rest...........................7
Compound Slide Rest Parts List................8
Compound Slide Rest Assembly..................9
Double Cross Slide Parts List................10
Double Cross Slide Assembly..................11
Swivel Slide.................................12
Tail Stock...................................13
Tool Post Turret.............................14
Tilted Head Turret...........................15
Tilted Head Turret Parts List................16
Tilted Head Turret Assembly..................17
Headstock Parts List.........................18
Headstock Assembly...........................19
Lubrication Diagram..........................20
Wiring Diagram...............................21
Accessories..................................22
Accessories..................................23
Accessory Notes..............................24
