R & s SMIQ03E signal generator 3.3 ghz opt B10 B11
Rohde and Schwarz Signal Generator Opt smiqb10 and smiqb11
The SMIQ03E has especially been designed for the needs in production, environments and satisfy the requirement for an economically attractive solution with an outstanding price/performance ratio.
Versatile and broadband generation of digitally modulated signals up to 7 Msymbol/s
Analog and digital modulation capabilities
Generation of TDMA and CDMA signals to all main mobile radio standards
Broadband I/Q modulator with outstanding vector accuracy
Optional internal fading simulator to test specifications of mobile radio standards
Frequency Range 300 kHz - 3.3 GHz. Frequency Resolution 0.1 Hz. Output Range -140 dBm to +13 dBm. Output Resolution 0.1 dB. Time Base Stability 0.000001 ppm. Spectral purity: Harmonics at level ?10 dBm <-30 dBc; SSB phase noise at 1 GHz, carrier offset 20 kHz, 1 Hz bandwidth; SMIQ02E/SMIQ03E CW <-116 dBc; Vector modulation: <-113 dBc. Modulation with SMIQ02E/SMIQ03E: Frequency/phase modulation internal, external AC/DC, two-tone with two modulation channels; with PM:
bandwidth 2 MHz only for channel 2 Max. deviation FM PhM, bandwidth 100 kHz/2 MHz depending on carrier frequency: 5 to 20 MHz, 50 to 200 rad/2.5 to10 rad. Modulation frequency range FM DC to 8 MHz. Digital standards with options SMIQB10 and SMIQB11: GSM, NADC, PDC, PHS, CDMA,
This unit powers on and passes all self test and lab test. Bright display and fully functional unit with Option B10 and B11. Ready to use.
