31" swg 156" cc hes jupiter 830 engine lathe, inch/metr
31" Swg 156" cc HES JUPITER 830 ENGINE LATHE, Inch/Metr
31" Swing 156" Centers HES JUPITER 830 ENGINE LATHE, Inch/Metric,Gap,3" Hole, Steady, 3-Jaw, Toolpos
MODEL: JUPITER 830, S/N: 5027, NEW: 1968
SWING OVER BED ........................... 31"
SWING IN NATURAL GAP 12" FROM SPINDLE ... 32-5/8"
SWING OVER CROSS SLIDE ................... 20-3/8"
DISTANCE BETWEEN CENTERS ................. 158"
WIDTH OF BED ............................. 20-1/4"
SPINDLE NOSE ............................. A1-8"
SPINDLE BORE ............................. 3"
SPINDLE SPEED RANGE (22) ................. 32 - 1600 RPM
INCH THREADING RANGE (24) ................ 2 - 28 TPI
METRIC THREADING RANGE (24) .............. 1 - 14
FEDD RANGE (24) .......................... .0045 - .055
QUILL DIAMETER ........................... 4-3/8"
QUILL TAPER BORE ......................... 6MT
MAX QUILL STROKE ......................... 9-7/8"
DIMENSIONS ............................... 240" x 66" x 60"
APPROX WEIGHT ............................ 14,000 LBS
- QUICK CHANGE TOOLPOST WITH HOLDERS
- COOLANT SYSTEM WITH REMOVEABLE CHIP PANS
INSPECT UNDER POWER IN OUR NEW JERSY WAREHOUSE
