Hp agilent 1661AS 102 ch 250 500 mhz la w 2CH scope
HP Agilent 1661AS 102 CH 250 500 MHz LA w 2Ch Scope
* Passes performance verification
* Includes 6 Pods, 5 pkgs grabbers , 2 pkg ground clips.
* All accessories included are shown.
The 1661AS 102 Channel Logic Analyzer features a new CPU design that improves performance and adds PC style mouse and keyboard connections, hard disk drive, printer interface and optional Ethernet LAN. "S" adds a built in 2 Ch Oscilloscope.
* State and timing channels: 102
* Setup/hold time: 3.5/0 ns to 0/3.5 ns
* State/timing memory depth: 4k on all channels, 8k on half channels
* Timing analysis modes and speeds (conventional): 250MHz on all channels, 500MHz on half channels
* Timing analysis modes and speeds (transitional): 125MHz on all channels, 250MHz on half channels
* Timing analysis modes and speeds (glitch): 125MHz on half channels
* State analysis speed: 100MHz
* Minimum detectable glitch width: 3.5 ns
* Scope: 2 Ch 250 MHz 1GSa/s
