Omron zx-LD300 photo-electric laser measurement sensor
Omron ZX-LD300 Photo-Electric Laser Measurement Sensor
This is a Used Omron ZX-LD300 Laser Measurement Sensor. This sensor is used in conjunction with a sensor amp (not included) and can detect a variety of distances and widths in industrial applications. Some common applications are Food and Beverage (liquid level, and cap level detection), Electronics (IC pin inspection and orientation), and Metal Thickness detection. These sensors were pulled from a working system.
Cosmetically, they are in good condition
* Five analog output options including 4-20 mA and four DC voltage
outputs, plus three discrimination outputs
* One-button teaching function or PC setup and monitoring software
* Operation monitoring and direct data logging capabilities
* Waveform monitoring eliminates oscilloscope use
* Resolution indicator displaying maximum application resolution
* LD300: Diffuse reflective, Spot beam, 300 +/-200 mm sensing distance
