New camozzi pro-fit® fitting p 6520-04-06 ( )
This is a bag (sealed) of 25 new Fittings.
The Original Camozzi design - 100% All-metal, nickel-plated brass gives equipment that stainless- steel look while eliminating the danger of broken plastic pieces. Full ID tube flow is always maintained for maximum Cv ratings and quick cycle times. Push-in and lock the tube quickly and effortlessly.
Low Profile Fit - New Pro-Fit fittings offer the lowest profile fit for tight places. Their unique design eliminates all exposed threads making them ideal for food processing and hygienic applications.
Fast Installation - Assembly is fast due to the lack of thread preparation often necessary with other brands. The shortened thread makes for Super- rapid installations. Just a few turns and the fitting is secure.
Perfect Seal - A captured teflon ring seated around the base of the hex shoulder makes for a perfect, reusable (SAE-type) seal every time. There is no risk of defiling pneumatic components susceptible to loose particles typical of conventional thread sealants.
MaterialBrass OT58 UNI 5705, nickel plated, PTFE seal ring
ColletBrass OT58 UNI 5705, nickel plated
O-ringBuna-N [viton available]
Threads1/8 , 1/4 , 3/8 , 1/2 NPTF
Operating pressureFrom0-250psi
Vacuum rating29 of Mercury Hg
Tube to connectNylon 6, 11, 12; Polyethylene, Polyurethane (recommended 90A durometer and above)
Tube diameter1/8 , 5/32 , 1/4 , 5/16 , 3/8 , 1/2
FluidCompressed air [for other types of fluid please contact our engineers]
Operating temperature0 F - 160 F
