2A breaker 1489A1C020 allen bradley 1489 A1C020
Allen-Bradley Part Number: 1489-A1C020
IF YOU NEED MORE THEN ONE PLEASE EMAIL!!!
UL489/CSA 22.2 No 5.1 Circuit Breaker, 1 Pole, Trip Curve C, 2 Amp, 277 VAC
Bulletin 1489 Circuit Breakers
* Energy-limiting design protects downstream components better than conventional breakers during short circuits
* Field-mountable options for selective applications
* IP2x Finger-Protection (Front)
* North America certifications: UL 489, CSA C22.2 No. 5.1
* International standards: CE Marked, and IEC (VDE) standards for worldwide acceptance
* Ratings: UL/CSA max. 480Y/277V AC 10 000 A interrupt rating;
IEC max. 240/415V AC 15 000 A interrupt rating
* 48V DC rating, 96V DC 2-pole series
* A positively trip-free mechanism (breaker operation cannot be defeated by holding the handle in the ON position)
* Superior shock and vibration resistance capabilities helps to prevent nuisance tripping
* Wire connect, line and load (reversible)
* Optional terminals for ring lug terminals
