Challenge EH3A 3 spindle drill eh-3A three hole punch
* Three Spindle Paper Drill
* Condition: Nice machine. Powered up and tested for full operation. This is a heavy-duty machine!
* The Challenge EH3A drills the most popular 3-hole patterns in one stroke as well as single and double hole patterns. It also features a deep 2 " drill capacity.
* Powerful Drilling Operation
* Fast and Easy Head Adjustments
* Flexible Backgauge Adjustments
* Range Between Drills: 2-3/4" to 4-1/2"
* Range Between Outside Drills: 5-1/2" to 9"
* Maximum Drilling Capacity: 2-1/2"
* Strokes per Minute (adjustable): Up to 18
* Backgauge Adjustment: 0 to 4-1/2"
* Vertical Adjustment of Individual Heads: 1/4"
