Vacuum chamber bell jar 600ASA pumping system varian
#1) The Vacuum Bell Jar System Outside:
Outside Dimension of whole unit(43 x 29 x 82 high)
Steel Channel Iron Fram (43 x 29 x 43 high)
4-Heavy Duty Roll around Casters for mobility
1-front see through port 3 7/8"ID, 6"OD plexy glass cover
A Stainless Steel Ring with 3-Front Latches for closure
#2)The Vacuum Bell Jar Inside:
Dimension (25 OD, 23 ID @ 29 high, inside)
**** 1-8 port with mesh screen
**** 13- Extra small ports capped
Electric Hoist to raise the Bell top
8 diam vent with 6 drop, under the Bell Jar
600ASA. 11 OD, 9.5 BCD @ 8 ID with 8 bolt holes
600ASA , 11 OD, 1 thick, reduced to a 2.75 CFF fixed conflat
*** (600ASA Model #60952 FlowLine 6 150 B16 F304L A182)
2.75 CFF rotate able conflat, reduced to a KF40
Extra small port to the left (1 NPT adapted to a 2.75 CFF conflat)
2.75 CFF conflat reduced to a KF25
This is a real nice piece that can easily be adapted to do that experimental vacuum chamber testing you would need to do.
PS: Please double click the scroll down photos to enlarge and thank you for looking and GOD bless.(B1038_s09)
