Starrett disc flange micrometer mics o to 25MM 256M
STARRETT DISC FLANGE MICROMETER MICS O TO 25MM 256M
These tools are used to measure the thickness of work sections such as ribs, lands, fins, cutting edges on form tools, and chordal thickness of gear teeth. Because of their large anvil and spindle faces, this mic is also useful for measuring the thickness of sheet materials like paper, cardboard, rubber, and plastics.
* Starrett satin chrome finish - no glare - resists rust
* Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
* Quick-reading figures - every thousandth numbered
* Convenient decimal equivalents on reading tools
* Ring-type knurled lock nut for quick and sure locking
* The combination ratchet and speeder for uniform pressure and quicker adjustment
* Gracefully designed tapered frame for use in narrow slots and tight places
* Anvil and spindle discs are 1/2" (12.7 mm) diameter tapering to .015" (0.4 mm) edge thickness making it possible to enter narrow grooves and recesses
* Rigid one-piece frame of drop forged steel
* Extremely hard and stable one-piece spindle (the heart of our accuracy)
* Micro-lapped measuring faces
This tool is accurate to .00015" or 0.003 mm measuring over the whole surface and .0002" or 0.004 mm measuring on the edges
I will fully guarantee this item with a cost of over $300 - "Proudly made in the US".
