11" Y Axis 18" X Axis Moore G-18 JIG GRINDER, HARD WAYS & SCREWS, OIL BATH FOR SCREWS,
TABLE SIZE .................................. 11" X 24"
TABLE TRAVEL (LONGITUDINAL).................. 18"
TABLE TRAVEL (CROSS) ........................ 11"
SPINDLE HOUSING VERTICAL TRAVEL ............. 12- 5/8"
SPINDLE VERTICAL TRAVEL ..................... 3- 5/8"
TABLE TOP TO WHEEL COLLET ................... 2" X 18"
SPINDLE TO COLUMN WAYS ...................... 10"
SPINDLE TO COLUMN BELOW WAYS ................ 13-1/2"
INFINITELY VARIABLE SPINDLE SPEEDS ...... 25 TO 225 RPM
INFINITELY VARIABLE SPINDLE FEEDS ........ 2 TO 120 SPM
SPINDLE FEED ADJUSTABLE FROM ......... 0.100" TO 3- 5/8"
GRINDING WHEEL SPEEDS ............. 6,000 TO 175,000 RPM
GRINDING CAPACITY (HOLE DIA.) ........ 1/64" TO 3- 1/2"
WITH EXTENSION PLATE ...................... 13- 1/2"
MAIN SPINDLE SLIDE ADJUSTMENT .............. 1-1/2 DEG.
EITHER WAY, 3 DEG. INCLUDED ANGLE
(A) - FROM CENTER TO 1-1/8" OFF CENTER BY ROUGH ADJ.
(B) - WHILE RUNNING .0001" ADJ. FOR DISTANCE OF .100"
APPROXIMATE WEIGHT .......................... 4,000 LBS
APPROX. FLOOR SPACE REQUIRED ..... 58"LR X 59"FB X 91"H
MINIMUM HEIGHT WITH HEAD IN DOWN POSITION ......... 86"
ELECTRONIC SERVO DRIVE PROVIDES INFINITELY
VARIABLE SPINDLE SPEEDS (25 TO 225 RPM)
HARDENED, GROUND AND LAPPED STEEL WAYS (NO GIBS)
HARDENED, GROUND & LAPPED NITRALLOY LEAD SCREWS
LEADSCREWS & NUTS ARE FULLY IMMERSED & OPERATE IN A
1/5 H.P. D.C. MOTOR (MAIN SPINDLE)
MOORE JIG GRINDING HEADS ..... CHOICE OF 40K OR 60K RPM.
PRESENTLY, THE MACHINE HAS A 40K RPM HEAD.
MACHINE IS WIRED FOR 220 VOLTS/1 PHASE/60 CYCLE ELECTRICS
** EXCEPTIONAL CONDITION - ORIGINAL PAINT!! **
