Pair of sti MCF4200 safety light curtains 20" MCF4220
Pair of STI MCF4200 Safety Light Curtains 20" MCF4220
* (1) MCF4220X-2 Transmitter (43403-0200)
* (1) MCF4220R-2 Receiver (43402-0200)
* Adjustable Mounting Brackets
* Response Time: <0.035 seconds
* Operating Range: 0 to 30 feet (9.1m)
* Beam Spacing: 0.5-inch (13mm) centers
* Min Object Resoluton: 0.75-inch (19mm) diameter
* Relative Humidity: 95% max. non-condensing
* Quick Disconnects: Circular, weather-tight glass-filled nylon
* Power: 115VAC, 50/60Hz standard; 230VAC 50/60Hz or 24VDC
* Highly immune to electromagnetic interference, strobe or ambient light interference and welding flash
