> 1986 kellenberger 600U id/od universal grinder w/dro
1986 kellenberger 600U id/od universal grinder w/dro
1986 KELLENBERGER 600U ID/OD UNIVERSAL GRINDER w/DRO
10" X 24" KELLENBERGER "SWISS" "HIGH-PRECISION"
UNIVERSAL I.D./O.D/FACE GRINDING CYLINDRICAL GRINDER
125mm FACTORY RISER BLOCKS AVAILABLE FROM
KELLENBERGER TO INCREASE THE SWING OF THIS MACHINE
TO 19- 5/8" (250mm CENTER HEIGHT)
MODEL: 600 U S/N: 32460-2264 NEW: 1986
HEIGHT OF CENTERS, WITH REMOVABLE RISERS ... 9- 27/32"
MAXIMUM SWING WITH FACTORY RISER BLOCKS ........ 19.8"
DISTANCE BETWEEN CENTERS (NOMINAL)........... 23- 5/8"
DISTANCE BETWEEN CENTERS W/TAILSTOCK
OVERHANGING ................................ 29- 1/2"
LONGITUDINAL TABLE TRAVEL ................... 35- 1/2"
COARSE .................................... 25/32"
FINE ...................................... 3/32"
LONGITUDINAL TABLE SPEED (HYDRAULIC) .. 0.06 TO 18' FPM
TABLE SWIVELS .............................. 11 DEGREES
REVERSING DWELL ........................ 0 TO 5 SECONDS
1 GRADUATION OF FEED SCALE ................ 0.0002"
AUTOMATIC FEED, MAXIMUM .................... 0.035"
AUTO. INFEED PER TABLE REV. ..... 0.00005" TO .0012"
INFEED FOR PLUNGE GRINDING ........ 0.00004" TO .002"
PLUNGE GRINDING: INFEED SPEED ... 10 TO 1000 uIN/SEC
MICROMETER STOP, 1 GRADUATION ............ 0.00005"
UNIVERSAL GRINDING SPINDLE HEAD:
TRANSVERSE MOVEMENT OF WHEEL SLIDE ........ 11-1/4"
HYDRAULIC RAPID WHEEL SLIDE ADVANCE/RETRACTION
STROKE .................................. 1-9/16"
GRINDING WHEEL SPEEDS (4) 1500, 1700, 2200 & 3600 RPM
GRINDING WHEEL FOR CYLINDRICAL
GRINDING .......................... 16" X 2" X 5"
GRINDING WHEEL (SURFACE GRINDING) .. 10" X 3/4" X 3"
SWIVEL OF GRINDING HEAD W/LOCKING EVERY
90 DEGREES ............................ 270 DEGREES
VERTICAL MOTION OF GRINDING SPINDLE HEAD,
HEIGHT OF CENTERS ......... 4-59/64" TO 13-25/32"
INFINIT. VARIABLE SPINDLE SPEEDS ........ 10 - 400 RPM
WORKHEAD SWIVELS ........................ 360 DEGREES
INSIDE TAPER OF WORK SPINDLE ................. #5MT
APPROXIMATE FLOOR SPACE REQUIRED .... 102" X 64" X 66"H
APPROXIMATE MACHINE WEIGHT .................. 6,000 LBS
HYDRAULIC OPERATION FEATURING:
-INFINITELY VARIABLE TABLE TRAVERSE
-RAPID WHEEL ADVANCE & RETRACTION
ADJUSTABLE CENTER HEIGHT FEATURE W/MAXIMUM SWING 19.8"
DUAL LEFT-HAND & RIGHT-HAND WHEEL MOUNTING
CURRENTLY SET-UP AS A 125mm CENTER HEIGHT MACHINE
(9.8" SWING) .... CAPACITY CAN BE INCREASED
.... SEE INFO ABOVE & BELOW ON KELLENBERGER
-SWING AROUND INTERNAL GRINDING ATTACHMENT
SWING AROUND INTERNAL GRINDING ATTACHMENT WITH
"DARENTH" MADE IN ENGLAND COOLANT SYSTEM WITH
HEIDENHAIN DIGITAL READOUT (2-AXIS DISPLAY)WITH
STANDARD WORKHEAD W/DUAL LIVE & DEAD WORKHEAD SPINDLE
125mm FACTORY RISER BLOCKS AVAILABLE FROM KELLENBERGER
TO INCREASE THE SWING OF THIS MACHINE TO 19- 5/8"
** EXCEPTIONAL CONDITION & APPEARANCE! **
Click Here For More Kellenberger Machines
