Allen-bradley 1305-AA12A 3HP vfd ac motor drive 2.2KW
Allen-Bradley 1305-AA12A 3HP VFD AC Motor Drive 2.2kW
This is a used Allen-Bradley 3 Horsepower 2.2kW Variable Frequency Drive (Cat. No. 1305-AA12A). This drive is in good cosmetic condition, with only minor scrapes and scratches from normal use.
No testing was performed on this item, as we do not have the means to test it. The item was pulled from a working environment.
The photos are of a typical unit. No manuals or additional accessories are included if not shown.
Allen Bradley 1305-AA12A Specs:
* Input: 200-230VAC, 50/60Hz, 12A, 2.2kW
* Output: 380-460VAC, 3Phase, 0-400Hz, 2.3A
Allen Bradley 1305-AA12A Performance Features:
* Capable of producing high torque across a wide speed range
* Easy-access power and control wiring through a hinged front panel
* Readily configurable for either two- or three-wire control
* Inherent dynamic braking for faster stopping
* IR compensation function increases power to the motor when it is needed most
* Fast acceleration times mean more cycles per minute, and translate into increased revenue
* Built-in protective features that save panel space and reduce installation costs
* The hybrid current limit function utilizes both firmware and hardware control to minimize the possibility of trips during shock loads, fast accelerations, constant speed operation and deceleration
* Intelligent power modules using IGBT technology
* Software configurable inputs
* S-Curve acceleration and deceleration
* Programming and/or Operation
* Optional Human Interface Module
* CE-Emissions, Immunity, Low Voltage
* Designed to Meet International Standards
* 200/230V, 380/460VAC 10%
* 0.5 Sec. Minimum (2.0 Sec. Typical)
* Voltage Adjustable from 0 Volts to Nominal Input Voltage
* Frequency Range 0-400 Hz, Programmable
* Frequency Resolution 0.01 Hz
* Continuous Current To 100% of Rated Current
* Intermittent Current To 150% for 60 Seconds
* Instantaneous Current Trip At 200% to 270%
* Accel/Decel 0.0-3600 Seconds in 0.1-second Increments
* Independently set (2 Accel, 2 Decel)
* Frequency 0 to120 Hz Minimum; 40 to 400 Maximum
* Stop Mode Ramp to Stop/Coast/DC Brake to Stop/S-Curve Stop
* Adjustable Current Limit 20 to 150%
* Preset Speeds 0-400 Hz, 7 Selections, Independently Set
Ambient Operating Temperatures
