> Fujikura hjs-02 hot jacket stripper made in japan good
Fujikura hjs-02 hot jacket stripper made in japan good
1 Fujikura HJS-02 Hot Jacket Stripper
The HJS-02 and HJS-03-24 hot jacket strippers provide superior ribbon and field- ribbonized stripping performance. They conserve power for field stripping when operating under battery power. A temperature selection switch is also provided for easy optimization in the field for different fibers or operating conditions. An optional single-fiber adapter may be used to provide easy, single-fiber capability for high strength splicing applications, or for single-fiber capability for difficult to strip fibers. These strippers also accept the fiber holders of the FSM-40F and FSM-40PM factory/lab splicers. An optional power assist tool for the HJS-03-24 allows smooth and controlled stripping of 24-fiber ribbons.
Applicable Fiber Count 1 to 12 Fiber Ribbon
Ribbon Thickness 250 m to 400 m
Typical Heating Time 3 sec Normal Mode 8 sec Power Save Mode
Standard Heating Temperature 100 C
Dimensions (W x D x H) 107mm x 40mm x 29mm
Operating Conditions -10 C to 50 C
Storage Conditions -40 C to 80 C
