Samsung S3C2440 ARM9 board +nec 3.5" tft+camera+wifi
Linux-ready hardware/software development kit for Samsung's ARM9-based S3C2440 microprocessor.
One of the smallest S3C2440 development board, 3.9 x 3.9 inches (100 x 100mm)
Samsung S3C2440's ARM920T RISC core at 400MHz (dominant frequency) and 533MHz (peak frequency).
The PCB on the MINI2440 board is designed to be 4-layers board, adopting the ENIG technology and professional equal-length wiring to ensure the completeness of the signals of the key signal wires.
Our specially designed panel frame enhances reliability through entirely solid-state operation without moving parts. You can carry this compact full-featured touch panel computer anywhere without worrying about missing parts
MINI2440 S3C2440 ARM9 Development Board (Preload with Linux)
NEC 3.5 TFT Touch Screen LCD
One DVD-ROM with English User Manual, Schematics, Demo code, Source code & Data Sheets
MINI2440 S3C2440 ARM9 Development Board Features
- Up to 4096 color STN, 3.5 inches to12.1 inches,
- Up to 64K color TFT, 3.5 inches to 12.1 inches,
- 4 wire resistive touch screen interface
- 1 10/100M Ethernet RJ-45(DM9000)
- 3 Serial Ports(1 RS232 with CTS and RTS)
- 1 Stereo audio out, 1 Micro In
- 1 POT can be used for A/D converter adjust
- Power In(5V), with switch and lamp
- 100 x 100mm, 3.6x3.6x0.7 inches
- Linux/Otopia support touch screen
Model: NL2432HC22 (QVGA Digital Screen)
Color RGB: 6-6-6 (262,144 colors)
Display area: 2.1 x 2.8 inch (53.64 x 71.52 mm)
Contour dimension: 2.5 x 3.3 x0. 2 inch (64.0 x 85.0 x 4.13 mm)
Video Capture: 640 x 480/1280 x 1024
Still Image: 640 x 480/1280 x 1024
WLAN 802.11B/G embedded module enables high-speed 54Mbps wireless connections to LAN services.
Integrated WLAN into embedded module devices makes it more convenient to get on the net everywhere you are.
