1992 miyano jnc-45S cnc lathe w/live tools, sub spdl
1992 MIYANO JNC-45S CNC LATHE w/LIVE TOOLS, SUB SPDL
MIYANO MODEL: JNC-45S CNC TURNING CENTER WITH LIVE TOOL AND SUBSPINDLE
BAR CAPACITY ROUND .......... 1-13/16"
MAX. SWING .................. 20-5/16"
MAX. WORK LENGTH ............ 15"
SPEED RANGE ................. 40-4000 RPM
SPINDLE NOSE ................ A2-6
SPINDLE MOTOR (30 min) ...... 15 HP
TURRET STATIONS ............. 10
REVOLVING TOOL STATIONS ..... 5
REVOLVING TOOL SPEED RANGE .. 200-4000RPM
REVOLVING TOOL DRIVE MOTOR .. AC 2/3HP
CUTTING TOOL SHANK SIZE ..... 3/4"
X-AXIS STROKE ............... 6-5/8"
Z-AXIS STROKE ............... 15"
RAPID TRAVERSE X/Z .......... 394/472 IPM
SUB SPINDLE SPEED RANGE ..... 100-4000 RPM
SUB SPINDLE MOTOR ........... 5HP
B-AXIS STROKE ............... 20.51"
RAPID TRAVERSE B AXIS ....... 394 IPM
APPROX. WEIGHT .............. 11,000 LBS.
- S20 COLLET CHUCK ON MAINSPINDLE
- S16 COLLET CHUCK ON SUBSPINDLE
- 10 POSITION TURRET WITH 5 LIVE STATIONS
- 5 DEGREE INDEXING ON MAINSPINDLE
- ALL AVAILABLE STANDARD TOOLHOLDERS
- COOL BLASTER HIGH PRESSURE COOLANT
- LNS 6.52HS-5.2 HYDROBAR BARFEED FOR 12' BARS
AIRCRAFT PARTS - MOSTLY STAINLESS STEEL - AND IS
EXTREMELY WELL MAINTAINED. THERE IS SOMEONE YOU CAN
SPEAK WITH AT THE SHOP ABOUT THIS ITEM. CALL US TO
