Underwater fishing camera+7"color lcd video system cctv
Underwater Fishing Camera+7"Color LCD Video System CCTV
* Underwater Camera is designed to connect to your TV, VCR, LCD TV or some Digital Video Camera/Camcorders with an A/V Input.
* Have provided "Gender Adaptors" in the case that your Digital Video Camera cannot accept male RCA plugs.
* The Underwatercam is ideal for use on your home TV or VCR (when using Underwatercam in the pool) or can be used on TV's found on cruise or dive boats, 12V portable VCRs or LCD Monitors (with RCA Input).
7 Inch TFT-LCD Color Monitor Specification:
* Resolution: 480(W) x RGB x 234(H)
* Operating Temperature: -10 ~ +50
* Storage Temperature: -20 ~ +60
* Image Sensor: 1/4 Sharp Color CCD
* Pixel Resolution: PAL: 500 x 582
* Electronic Shutter: 1/60~1/5000 Sec
* Lens Angular Field of View: 60 Degree
* Effective Focal Length: 6mm, 9 Light
* Maximum Relative Aperture: F/2.0
* Video Signal Output: 1V(p-p) Composite Video Signal at 75ohm Termination
* Packaging Material: High Impact ABS Plastic
* Operating Temperature: -50 ~+160
1. 7-inch TFT LCD underwater Video System.
2. 60deg Camera Vision Angle.
4. Horizontal Resolution: 420TV lines.
7. Waterproof Camera Cabinet.
AC110/220V, 60/50Hz AC Adaptor (with Adaptor)
Battery power supply (rechargeable Batteries included).
11. Easy carrying aluminum case.
* 1 x 7" inch Color TFT LCD Monitor
* 1 x Underwater Camera with Cable
* 1 x DC 12V Battery Charger
* 1 x 12V Sealed Lead-Acid Rechargeable Battery (Optional)
* 1 x Connector (for Battery charging only)
