1500 cfm (218 sq ft) young pulse jet dust collector
1500 CFM (218 SQ FT) YOUNG PULSE JET DUST COLLECTOR
MANUFACTURED BY YOUNG INDUSTRIES IN 1989, SHOP NUMBER 9881-11, SIZE NUMBER HW-48-42, SERIAL NUMBER HW-3915, INTERNAL AND EXTERNAL PRESSURE RATING 5.89 PSI AT 350 F. SHELL THICKNESS 0.1345". CARBON STEEL CONSTRUCTION. BAGS MOUNT IN HORIZONTAL DIRECTION AND ARE REMOVABLE FROM THE CLEAN AIR SIDE OF COLLECTOR. UNIT HAS 8" DIA. FLANGED INLET AND OUTLET. PRODUCT HOPPER HAS 6" DIA. OUTLET AND 20" BY 20" SQUARE FLANGED ACCESS PANEL. UNIT HAS FOUR MOUNTING ANGLES FOR INSTALLING LEGS ( LEGS ARE NOT WITH UNIT). UNIT IS 74" WIDE BY 64" WIDE BY 105" OVERALL HEIGHT. BAGS ARE 48" LENGTH X 42 BAGS. SOME PARTS MISSING. UNITS ARE UNUSED.
