Trailer plans- flat bed deck sand rail atv car CJ5
Photo Sharing and Video Hosting at Photobucket Photo Sharing and Video Hosting at Photobucket Photo Sharing and Video Hosting at Photobucket Photo Sharing and Video Hosting at Photobucket Photo Sharing and Video Hosting at Photobucket
ON A TRAILER THAT STORES IN YOUR GARAGE
NOTE- TONGUE HINGES FOR GARAGE STORAGE
THE UPPER DECK CAN ALSO BE REMOVED
* SIMPLE DESIGN ALLOWS UPPER DECK AND LEGS TO BE EASILY REMOVED IF DESIRED
* UNIQUE BUT STURDY TONGUE DISIGN- TONGUE IS EASILY RAISED BY PULLING 2 PINS AND LIFTING AND LATCHING IT IN THE VERTICAL POSITION
* DESIGN ALLOWS CARRYING OF UP TO THREE ATV S AND A CAR
* DESIGN INCLUDES 8 FOOT RAMPS FOR WINCHING ATV'S TO UPPER DECK
* TOTAL GARAGE LENGTH REQUIRED 16'- 8"
* 8 FOOT RAMPS STORE UNDER UPPER DECK
* REDUCE THE RISK OF THEFT BY KEEPING YOUR MACHINES OUT OF EASY REACH
* WHEN TOWING IN INCLEMENT WEATHER, ATVS DO STAY SIGNIFICANTLY CLEANER THAN IF TOWED AT GROUND LEVEL
* TRAILER WEIGHT 2300-2500 LB
* CAPACITY- UPPER DECK 1000 LB
* DECK WIDTH UPPER- 8'-0", LOWER- 6'-10"
These plans are based on the trailer which you see in these pictures. We made it several years ago. It is similar to my lowerable deck trailer which has the upper deck which is lowered using a small winch(see other listing). This trailer is quite a bit easier to make than the lowerable deck trailer but not quite as flexible in usage. The upper deck is capable of carrying 1000 pounds, with a total of 4500 pounds on both decks.
The construction of this trailer is not difficult but does require reasonably good welding skills and the ability to read and understand mechanical drawings. The time required for construction is about 2 weeks depending on your skills and effort.
The cost for parts and materials for building this trailer is between $1800 and $2700 depending on what kind of friendly prices you can get for the components and how fancy you want to make it.
NOTE: I also have plans for just the base trailer with no upper deck and with foldable tongue. See my other listings.
