Xante platemaker 5 110V 256MB ram 2400X2400
Xante Platemaker 5 Total Prepress System 110V 256 MB ram 2400 X 2400 resolution. Built in 2006. In very good condition. This was used in my print shop that I had to shut down.
Exact halftones. Accurate registration. Sharp images. Crisp film. Clean plates. This chemical-free, process-free, total prepress system images paper proofs, film and polyester plates. Choose freedom from your tired process and go digital.
With our PlateMaker5 total prepress system, processing is eliminated. Go from proofs to approval and directly to plate or film using only one device. Your plate production is completely process-free and chemical-free. Our Z-7 Technology assures clean plates, crisp film, sharp images and exact halftones - in a word, detail. That's pure CTP technology.
Our PlateMaker5 system, accompanied by the Myriad 2 plate, gives you the feel of metal on your press. Myriad 2 plates are among the best conventional polyester plates on the market with run lengths of 20,000 impressions or more. The grained surface of the Myriad2 plate allows it to hold very small halftone dots. The ability to generate 120 plates per hour saves you time and money. Myriad2 positive or negative film can be used to burn larger metal plates for your wide-format presses.
With our PlateMaker5 total prepress system, most print shops can realize a 100% return on their investment in less than a year. Turn "if only we could" into "now we can." You can custom-fit the PlateMaker5 to fit your workflow and enable your shop to reach peak performance. That's the bottom line.
Z-7 Technology:Z-7 assures clean plates, crisp film, sharp images, accurate registration and exact halftones - in a word, detail. Incorporating our unique Z-Dot screening, the PlateMaker5 delivers the cleanest screens possible from an electro photographic process.
Clean Plate Technology (CPT):This technology has been built from the ground up to create a perfect plate with no cleaning or special etch required, giving you the unprecedented ability to print numerous polyester plates that go straight to the press.
Adobe Postscript 3 :True Adobe PostScript 3 offers reliability, increased performance, and the assurance of compatibility to work from virtually any software application and hardware environment.
Advanced Halftone Calibration:The PlateMaker5 leaves little to chance when it comes to matching plate output to the characteristics of your press. Both an automated Quick Calibration and an Advanced Calibration feature allow you to fine tune the PlateMaker5 to your specific environment.
Negative Enhanced Imaging Technology (NEIT):This patented technology allows you to produce superior quality negatives ensuring clear, crisp hairline images and text without the risk of "plugging," which occurs when printing negative images on typical laser printers.
XANTE Accurate Calibration Technology (X-ACT ):Our patented Accurate Calibration Technology gives you precise control over horizontal and vertical dimensions on page images ensuring unmatched output accuracy.
Non-electrostatic Plates:Supports chemical-free plate making using Myriad 2 polyester plates, making computer-to-plate printing more cost effective and less time consuming.
Myriad Film:Polyester-based Myriad film has been developed specifically to create quality film directly from your computer.
Negative Print:Provides the ability to print a negative image from any application regardless of job make-up.
User-Friendly Web Interface:Enter the IP address of the printer in the address bar of your Web browser to check the printer status, rename it, align plates and more.
Multi-Plate Loader:You have more things to do than single-feed plate loading. The auto plate loader allows you to stack up to 50 Myriad2 polyester plates, walk away and return to crisp, clear output.
Auto Plate Loader 50 plate capacity
Dimensions Width 22.8" (58 cm), Depth 23.68" (60.2 cm) with cassette, Height 16.24" (41.3 cm)
Hard Drive Optional 2.5" (6 cm) internal IDE drive
Imaging Speed Up to 120 plates per hour
Imaging Unit Self Contained Proprietary
Imaging Unit Life 7,000 sheets (letter; 5% coverage)
Maximum Plate Size 13.38" x 25" (340 mm x 635 mm) - requires 340mm Option
Maximum Plate Size for Proofing 13" x 25" (330 mm x 635 mm)
13"x18.5" (12.69"x18.42" print area); 330mm x 469mm (322mm x 468mm print area);
13"x25" (12.69"x24.72" print area); 330mm x 635mm (322mm x 628mm print area);
13"x35.5" (12.69"x35.23" print area); 330mm x 901mm (322mm x 895mm print area);
B4; B5; COM 10; Monarch; DL; C5
Media Weights 16 to 28 lbs. (60 - 105 g/m2) cassette tray; 4 mil (0.1 mm) plates - Plate Auto Loader
optional 2.5" internal IDE drive
Noise Level Printing - less than 49.5 dB; Standby - less than 35 dB
Optional Input Addition of a 500-sheet cassette. Two optional paper feeders may be installed for a maximum input of 1,650 sheets of paper.
Paper Input 500-sheet cassette (standard)
Plate Run Length >20,000 Impressions
Power Requirements 100-127 V ~ 50/60 Hz, 6.5 A
RIP Internal Adobe PostScript 3
Screening Technology Z-Dot / Traditional screens
Standard Interfaces Simultaneously active 10/100BaseT Ethernet (EtherTalk , TCP/IP, LPR, IPP) and Parallel Port
Standard Output 500 sheets maximum, face down
The 340 mm Option For plates up to 340 mm (13.38") wide (standard 330 mm)
Typefaces 136 resident PostScript Typefaces; TrueType 42 font rasterizer; Types 1, 3, 4, 5, and 6 PostScript download font support
