Leviton surge suppressor protector unit 3øy 277/480V
Leviton Surge Suppressor Protector Unit 3 Y 277/480V
NEW Leviton 52277-7M3 7-mode modular-mount surge protection panel. Rated 277/480VAC, 3-phase WYE (4-wire & ground). Features include:
* Verifies fail-safe conditions for MOVs under steadystate overvoltage
* Provides Normal Mode (phase to neutral) & Common Mode (neutral to ground) protection for WYE-configured 3-phase AC systems
* Max surge current (test w/8x20s wave) (L-N+L-G=per phase): 100KA/100KA/200KA
* UL 1449 (2nd Ed) Impulse(6kV/500A): 800 (L-N); 800 (L-G); 800 (N-G); 1500 (L-L)
