> New jet 22-44 oscillating drum sander kit 659006K
New jet 22-44 oscillating drum sander kit 659006K
JET 22-44 Oscillating Drum Sander Kit With Closed Stand
* Oscillating feature reduces heat build-up on sanding belt to reduce loading and burning
* Infinitely variable-feed control produces the ultimate finish at a rate from 0 to 10 feet per minute
* Patented conveyor belt TRACKERS dramatically reduce the need for manual belt adjustments
* Precision-flattened reinforced steel conveyor bed and no-give power feed belt provide a constant smooth sanding action for better results
* Large cast-iron handwheel adjusts height at 3/32" per turn for precise sanding thickness control
* Depth gauge has locking stop to ensure accuracy
Motor 1-3/4 HP; 1 Ph 115; Pre-wired 115V Drum Speed 1,700 RPM Drum Dimensions 5" x 22" Minimum Board Length 2-1/4" Maximum Board Thickness 4" Minimum Board Thickness 1/32" Maximum Board Width 44" Dust Port Diameter (OD) 4" Conveyor Speed 0 to 10 SFPM Amps 9 Amps Conveyor Motor Yes Overall Dimensions 46.6" x 23.5" x 15" (L x W x H) Net Weight 336 lbs.
* 22-44 Oscillating Drum Sander Kit With Closed Stand - 659006K
