Vermeer V1350 honda gas walk behind chain trencher
VERMEER V1350 HONDA GAS WALK BEHIND CHAIN TRENCHER
Hello: Up for sale is a VERMEER V1350 WALK BEHIND TRENCHER. It comes with a Honda GX390, 13 hp motor. This has the new very easy to operate Hydraulic drive wheels. It is also set up with the hydraulic drive chain for superior trenching and excellent safety and ease of use. Note the very low hours of approx 600hrs since new and you can see that this is one very excellent unit for the money. Look close at the pics and call with any questions.
Basic tractor with 24" (61 cm) boom and
Length: 80" (203 cm) transport
Height: 49" (124 cm) transport,
Trench width: 4" 6" (10 cm 15 cm)
Digging chain tensile strength:
Net flywheel HP at full-load RPM:
Max. operating angle: 20 (Not a machine
stability specification. Do not use it to
determine safe machine operating angle.)
Fuel-tank capacity: 1.7 gal. (6.4 L)
Engine-oil capacity: 2.3 pt. (1.1 L)
Oil-tank capacity: 4.5 gal. (17.0 L)
Oil-system capacity: 5 gal. (19 L)
Filtration: 10 micron, spin-on
Tires: Two 16 x 6.5 x 8 drive tires,
one 13 x 5.00 6 trailing tire
Optional 18 x 8.5 x 8 drive tires
Forward 0 116 fpm (0 35.4 m/min.)
Reverse 0 116 fpm (0 35.4 m/min.)
