1988 mori seiki sl-25B/1000 w/fanuc 10T - see video
1988 MORI SEIKI SL-25B/1000 w/FANUC 10T - SEE VIDEO
http:// /watch?v=_A6vETXxubU
SWING OVER BED ............................ 20.5"
SWING OVER CROSS SLIDE .................... 13.8"
DISTANCE BETWEEN CENTERS .................. 44.3"
MAX MACHINING DIAMETER .................... 10.2"
STANDARD MACHINING DIAMETER ............... 9.1"
MAX MACHINING LENGTH ...................... 40.6"
X-AXIS TRAVEL ............................. 6.3"
Z-AXIS TRAVEL ............................. 42.9"
SPINDLE SPEED ............................. 35 - 3500 RPM
SPINDLE HOLE DIAMETER ..................... 3.1"
WORK CAPACITY FOR BARS .................... 2.7"
SPINDLE NOSE .............................. A2-6
NO. OF TOOL POSITIONS ..................... 10
RAPID FEED RATE X-AXIS .................... 472.4 IPM
RAPID FEED RATE Z-AXIS .................... 590.6 IPM
TAILSTOCK STROKE .......................... 39"
TAILSTOCK QUILL DIAMETER .................. 4.3"
TAILSTOCK QUILL STROKE .................... 3.9"
MAIN MOTOR ................................ 20 HP
FLOOR SPACE ............................... 141.6" x 60.6"
