40-400X student compound microscope w fluorescent light
This versatile and value priced microscope is designed for K-12 students. The CM301 microscope is equipped with three high quality DIN standard objectives and a widefield WF10X/18 eyepiece with built-in scale and pointer. Green Friendly fluorescent light provide bright, cool and safe illumination.
The eyepiece is secured on the eyepiece tube by a set screw to prevent from dropping off. Separate coarse and fine focus knobs for ease of use with a slip clutch system to protect gears from eager students. The reversed nosepiece usually only exists in high end research level microscopes.
Widefield WF10X/18 with built-in pointer and scale, secured by set screw
Achromatic DIN standard 4X, 10X, 40X (spring, sealed)
Monocular, 45 Inclined, 360 rotatable
Revolving, triple, reverse facing
Plain stage, 2 stage clips, dimension 114mm X 125mm
with condenser and aperture diaphragm
Separate coarse and fine focusing knobs on both sides, built-in slip clutch, adjustable rack stop, tension adjustment with a wrench
Transmitted, fluorescent light
11-1/4" x 5-7/8" x 14" (28.5 cm x 15 cm x 35.5 cm)
* Eyepiece: WF10X/18 (installed)
* Objectives: DIN 4X, 10X, 40X (installed)
* Plan, semi plan objectives
Click the button above to view the list of accessories compatible with this product CM301
